ANON China agricultural manuel and intelligent AB point UAV drone crop sprayer UAV drone
Specification of agriculture crop sprayer 15kg 20kg UAV drone
Specification of agriculture crop sprayer 15kg 20kg UAV drone
Model | ANC-20 |
Material | aeronautical carbon fiber+aeronautical aluminum(waterproof shell,easy dismantling,portable foldable, high breaking strength) |
Unfolded Dimension | 2450X1300X800mm |
Folded Dimension | 850X780X700mm |
Max Take-off Weight | 34kgs |
Max pesticide load | 20kgs(remote liquid monitoring,breakpoint continuous spraying,floght altitude,flight radius, flight time,flight speed) |
Flight Altitude | less than 2000m(suggest 1-3meters at the top of crops) |
Flight Radius | less than 2000m |
Flight Time | 15-20min |
Flight Speed | 1-10m/s(cruise control) |
Working width | 3-5m (anti-floating pressure nozzle) |
Spray flow | 1-2L/min(automatic flow control,low liquid pull alarm) |
Control efficiency | less than 800mu/day |
Safe takeoff and landing | less than 5 levers(suitable for a certain wind) |
Power system | 24V polymer lithium battery(fast charging,energy saving and environmental pretection) |
Flight mode | manuel and intelligent AB point(fixed height, fixed point,automatic return,out of control return,low voltage return,AB point learning function,full self-planning flight breakpoint memory,breakpoints continue to spray) |
